Shaft Length Is 2750mm Motor Power Is 7.5kw Feed Screw Conveyor

Working principle:

When the rotor of the vane pump rotates, under the action of centrifugal force and pressure oil, the tip of the vane is closely attached to the inner surface of the stator. In this way, the working volume formed by the inner surfaces of the two blades, the rotor and the stator, first sucks oil from small to large, and then discharges oil from large to small. When the blades rotate one circle, oil absorption and oil discharge are completed once.

Working principle of single-acting vane pump

The pump is composed of rotor 1, stator 2, blades 3, oil distribution plate and end cover. The inner surface of the stator is a cylindrical hole. There is an eccentricity between the rotor and the stator. The blades can slide flexibly in the slots of the rotor. Under the action of the centrifugal force during the rotation of the rotor and the pressure oil at the root of the blade, the top of the blade is attached to the inner surface of the stator, so two adjacent blades, the oil distribution plate, the stator and the rotor Formed a sealed working cavity. When the rotor rotates in a counterclockwise direction, the blades on the right side of the figure extend outward, the volume of the sealed working chamber gradually increases, and a vacuum is generated, so oil is sucked in through the oil suction port 6 and the upper window of the oil distribution plate 5. And on the left side of the picture. The blades retract inward, and the volume of the sealed cavity is gradually reduced. The oil in the sealed cavity is pressed out through another window of the oil distribution plate and the oil pressure port 1 and output to the system. This kind of pump sucks oil and pressurizes oil once during one revolution of the rotor, so it is called single-acting pump. The rotor is subjected to radial hydraulic unbalanced force, so it is also called unbalanced pump, and its bearing load is relatively large. The displacement of the pump can be changed by changing the eccentricity between the stator and the rotor, so this kind of pump is a variable pump

Jiangsu SunRise Environmental Technology Co., Ltd. is located in Xuzhou, the beautiful capital of construction machinery. Founded in 2016, it is a comprehensive environmental protection company focusing on animal protein and grease recycling, food waste treatment, and sludge reduction treatment as a technology company.

The company has the most advanced technology and technology in the industry, more than 20 engineers, more than 100 technicians, and a standard factory building of 20,000 m2. The company was rated as a top high-tech enterprise in 2018. The main body of the team is a group of young people with ideals, aspirations, and innovation, with an average age of 35. We will rely on the unremitting efforts of all employees to develop domestic and foreign markets, and provide customers with advanced technology and Equipment, continue to create greater value for customers.
