    Carbon Steel 22KW 70m/Min Conveyor System Lamella Pump

    Ask Lasest Price
    Brand Name : Jiangsu Sunrise
    Model Number : YPB3522
    Price : Negotiate
    Payment Terms : T/T
    Supply Ability : 1 unit 30day
    Delivery Time : 30day
    Certification : ISO9001
    • Product Details
    • Company Profile

    Carbon Steel 22KW 70m/Min Conveyor System Lamella Pump

    Carbon Steel Convey Broken Materials Material Transfer Pump

    The raw material transfer pump produced by Jiangsu SunRise is used for the transportation of raw materials after crushing. It is specially designed for large-particle, high-viscosity biological materials. It is mainly used for whole raw fish, cooked fish, fish gills, slaughterhouse internal organs, The transport of materials such as poultry viscera and broken animal carcasses.

    The raw material transfer pump is a positive volume pump. During the operation, the volume of the transfer chamber changes with the change of the blade, so that the material works between the feed and the discharge, and the discharged material is transported by pipeline to avoid contact with the outside. The blade and the conveying cavity are made of special wear-resistant materials, which ensure the reliability of use and replaceable design, which improves the convenience of later maintenance.

    model no#35
    max theoretical capacity105m³/h
    max capacity20-50m³/h
    max recommended speed70 S/Min
    theoretical flowing capacity25L/Sev
    solid particle transport85mm
    min recommended pipe interface(outlet)250mm
    motor power5.5kw
    motor brandSimens
    Reducer brandJIE
    shaft brandSKF
    shipping size21155*1815*915
    shipping weight1300kg
    blade and inner ring materialHardox 500


    Quality Carbon Steel 22KW 70m/Min Conveyor System Lamella Pump for sale
